layout: true class: animated fadeIn middle numbers .footnote[ `IPS-DEV` - N. Dubray - ENSIIE - 2024 - [:book:](../index.html) ] --- # Doxygen .hcenter.w30[] ## Key points * documentation generator * supports `C++` (originally), `C`, `C#`, `Objective C`, `Fortran`, `PHP`, `Python`, etc... * interprets special comments in the source code **and the source code itself** * generates documentation pages in `HTML`, .latex[L<sup>a</sup>T<sub>e</sub>X], `PDF`, etc... * understands `Markdown` syntax and numerous specific commands ## Main ideas 1. The documentation is **in the code**, so it is easier to keep the code and the documentation **in sync**. 2. Developers are encouraged to document their code in a standardized format **when they write it**. .block[ * Repository: [https://github.com/doxygen/doxygen](https://github.com/doxygen/doxygen) * Website: [http://www.doxygen.org](http://www.doxygen.org) * License: `GPL` ] --- # Example of a documented code ## .hcenter[`[test.cpp]`] ```C++ /** * @file test.cpp */ /** * A global variable. */ int global = 0; /** * A very simple test function. * * This function is for test purposes only. * The returned value should not be used for anything serious. * * If you have any remark concerning this function, please append it to the file /dev/null. * * @param arg0 This is the first argument. It should be ignored. * @param arg1 This is the second argument. It should also be ignored. * @return The returned value can be used as a neutral element for the addition operation. */ double testFunc(int arg0, int arg1) { return 0.0; // Not very useful... } ``` --- # Generate the documentation <div data-dir='scripts/toto6' class='cinescript'></div> --- # Browse the documentation .shadow.hcenter.w90[] .hcenter[ [`HTML` documentation pages](test_doxygen/doc/html/index.html) ] --- # Configure `Doxygen` ## Tweak the generic configuration file ```shell *$ doxygen -g Doxyfile Configuration file `Doxyfile' created. Now edit the configuration file and enter doxygen Doxyfile to generate the documentation for your project *$ vim Doxyfile # tweak !!! $ doxygen [...] ``` ## .hcenter[`[Doxyfile]` (sample)] ```text [...] # This tag specifies the encoding used for all characters in the config file # that follow. The default is UTF-8 which is also the encoding used for all text # before the first occurrence of this tag. Doxygen uses libiconv (or the iconv # built into libc) for the transcoding. See http://www.gnu.org/software/libiconv # for the list of possible encodings. # The default value is: UTF-8. *DOXYFILE_ENCODING = UTF-8 # The PROJECT_NAME tag is a single word (or a sequence of words surrounded by # double-quotes, unless you are using Doxywizard) that should identify the # project for which the documentation is generated. This name is used in the # title of most generated pages and in a few other places. # The default value is: My Project. *PROJECT_NAME = "My Project" [...] ``` --- # Configure `Doxygen` ## Use a GUI ```shell $ doxywizard ``` .shadow.hcenter.w100[] --- # Undocumented function ## .hcenter[`[test.cpp]`] ```C++ /** * @file test.cpp */ /** * A global variable. */ int global = 0; /** * A very simple test function. * * This function is for test purposes only. * The returned value should not be used for anything serious. * * If you have any remark concerning this function, please append it to the file /dev/null. * * @param arg0 This is the first argument. It should be ignored. * @param arg1 This is the second argument. It should also be ignored. * @return The returned value can be used as a neutral element for the addition operation. */ double testFunc(int arg0, int arg1) { return 0.0; // Not very useful... } *void undocumentedFunc(void) *{ * printf("This function is not documented !\n"); *} ``` --- # `Doxygen` output ## Generate documentation ```shell $ doxygen [...] Generating style sheet... Generating search indices... Generating example documentation... Generating file sources... Generating file documentation... Generating docs for file test.cpp... */home/dubrayn/temp/dubrayn.github.io/IPS-DEV/test_doxygen/test.cpp:27: warning: Member undocumentedFunc(void) (function) of file test.cpp is not documented. Generating page documentation... Generating group documentation... Generating class documentation... Generating namespace index... Generating graph info page... Generating directory documentation... Generating index page... Generating page index... Generating module index... Generating namespace index... Generating namespace member index... Generating annotated compound index... Generating alphabetical compound index... Generating hierarchical class index... Generating graphical class hierarchy... Generating member index... Generating file index... Generating file member index... Generating example index... [...] ``` --- # `Doxygen` syntax ## Special comment blocks .row[.w48[ ```text /** * ... text ... */ ```] .w48[ ```text /*! ... text ... */ ```]] .row[.w48[ ```text /// ///... text ... /// ```] .w48[ ```text //! //!... text ... //! ```]] .row[.w48[ ```text /*****************************************//** * ... text ... ********************************************/ ```] .w48[ ```text ////////////////////////////////////////////// /// ... text ... ////////////////////////////////////////////// ```]] ## Brief description .row[.w48[ ```text /// Brief description. /** Detailed description. */ ```] .w48[ ```text //! Brief description. //! Detailed description //! starts here. ```]] ## Documentation after declaration .row[.w48[ ```C++ int var; /*!< Detailed description*/ ```] .w48[ ```C++ int var; ///< Brief description ```]] --- # Some `Doxygen` commands ## File description ```C++ /*! \file file.h * A brief file description. * A more elaborated file description. */ ``` ## Class / method / enum / etc... properties ```C++ /*! * \brief A trully random class. * \details This class is used to demonstrate a number of section commands. * \author John Doe * \author Jan Doe * \version 3.14a * \date 2021-2024 * \pre First initialize the system. * \bug Not all memory is freed when deleting an object of this class. * \warning Improper use can crash your application * \copyright GNU Public License. */ class SomeRandomClass {}; ``` ## Main page ```C++ /*! \mainpage My Personal Index Page * * \section intro_sec Introduction * * This is the introduction. * * \section install_sec Installation * * \subsection step1 Step 1: Opening the box * * etc... */ ``` --- # Conclusions on `Doxygen` ## In **your** code * write the special comment blocks **while** you code * use `Doxygen` commands * stick to the documentation guidelines * use `Doxygen` output to check for undocumented objects * use `Doxygen`'s mainpage to add general documentation ## In **other** code using `Doxygen` * generate the documentation if needed * **browse the generated documentation** * use the generated documentation as a source for * API / class reference * examples * use cases * etc...
