# Python virtual environments & package management

.hcenter.shadow.w100[![](images/vr.jpg)]

---

# Introduction

## Possible scenarios

1. a Python project needs some specific dependencies to be used
1. a Python project has a bug in a specific environment and you have to fix it
1. a Python project has non-orthogonal dependencies vs. another project (**or your system**)
1. a Python project has a dependency that breaks another project (**or your system**)

:bulb: How about having **separate** Python environments with specific dependencies ?
:arrow_right: **Virtual environments** to the rescue !

## Virtual environments

:arrow_right: allows to manage and use a full `Python` stack in a given directory.
:arrow_right: can also be used with non-Python tools/libraries.

## Other solutions

:arrow_right: VM, containers, chroot, etc...
:arrow_right: These solutions offer **encapsulation mechanisms** compared to virtual environments.

---

# Virtual environments

## Why use a virtual environment ?

* to test a new version of a module without stopping a service using it:
 * `criticalService` is running with `superModule==0.9.89`,
 * you think that you have fixed a bug in `superModule==0.9.90`,
 * you want to test `superModule==0.9.90` without stopping or changing `criticalService`...
 * **variant:** use two different versions of the same module on the same system.
* to reproduce a specific user environment (bug hunting):
 * client: "I was using `py27` + `numpy==1.19.3` and it crashed !"
 * you: "I tested with `py27` + `numpy=1.18.7` and it was fine !?"
* to test a project in different environments :
 * does it work with `py36` + `numpy==1.21.5` ?
 * does it work with `py38` + `numpy==1.20.1` ?
* to build a package in a "pure" environment:
 * a heavily-tweaked module `superModule==0.9.89a` is deployed system-wide,
 * you **do NOT want** it to alter the build process of your package...
* to avoid breaking the system by mixing package versions:
 * my project needs `setuptools==59.6.0`,
 * so I install it **system-wide** (`apt install ...`),
 * oops! I broke 30% of my Python system tools... (this is a fictionous example)...
* etc...

---

# Module `venv` - Usage demo

## If needed, install the Python `venv` module

```bash
$ sudo apt install python3-venv
```

:bulb: Install system-wide with the distribution package system.
:arrow_right: It should be installed by default on a standard Python installation (not like `virtualenv`).


## Usage demo

<pre><code><font color="#FFFFFF">[</font><font color="#FFFD00">dubrayn</font><font color="#FFFFFF">@</font><font color="#23FD00">dell5290</font><font color="#FFFFFF">:</font><font color="#14FFFF">/tmp</font><font color="#FFFFFF">]</font> <font color="#19CB00">which</font> python3
/usr/bin/python3
<font color="#FFFFFF">[</font><font color="#FFFD00">dubrayn</font><font color="#FFFFFF">@</font><font color="#23FD00">dell5290</font><font color="#FFFFFF">:</font><font color="#14FFFF">/tmp</font><font color="#FFFFFF">]</font> <font color="#19CB00">which</font> pip3
/usr/bin/pip3
<font color="#FFFFFF">[</font><font color="#FFFD00">dubrayn</font><font color="#FFFFFF">@</font><font color="#23FD00">dell5290</font><font color="#FFFFFF">:</font><font color="#14FFFF">/tmp</font><font color="#FFFFFF">]</font> <font color="#19CB00">ls</font> myVenv
ls: cannot access 'myVenv': No such file or directory
<font color="#FFFFFF">[</font><font color="#FFFD00">dubrayn</font><font color="#FFFFFF">@</font><font color="#23FD00">dell5290</font><font color="#FFFFFF">:</font><font color="#14FFFF">/tmp</font><font color="#FFFFFF">]</font> <font color="#19CB00">python3</font> -m venv myVenv
<font color="#FFFFFF">[</font><font color="#FFFD00">dubrayn</font><font color="#FFFFFF">@</font><font color="#23FD00">dell5290</font><font color="#FFFFFF">:</font><font color="#14FFFF">/tmp</font><font color="#FFFFFF">]</font> <font color="#19CB00">ls</font> <u style="text-decoration-style:single">myVenv</u>
<font color="#1A8FFF"><b>bin</b></font>  <font color="#1A8FFF"><b>include</b></font>  <font color="#1A8FFF"><b>lib</b></font>  <font color="#14FFFF"><b>lib64</b></font>  pyvenv.cfg
<font color="#FFFFFF">[</font><font color="#FFFD00">dubrayn</font><font color="#FFFFFF">@</font><font color="#23FD00">dell5290</font><font color="#FFFFFF">:</font><font color="#14FFFF">/tmp</font><font color="#FFFFFF">]</font> <font color="#19CB00">source</font> <u style="text-decoration-style:single">myVenv/bin/activate</u>
<font color="#FFFFFF">[</font><font color="#FFFD00">dubrayn</font><font color="#FFFFFF">@</font><font color="#23FD00">dell5290</font><font color="#FFFFFF">(</font><font color="#FD28FF">myVenv</font>):<font color="#14FFFF">/tmp</font><font color="#FFFFFF">]</font> <font color="#19CB00">which</font> python3
/tmp/myVenv/bin/python3
<font color="#FFFFFF">[</font><font color="#FFFD00">dubrayn</font><font color="#FFFFFF">@</font><font color="#23FD00">dell5290</font><font color="#FFFFFF">(</font><font color="#FD28FF">myVenv</font>):<font color="#14FFFF">/tmp</font><font color="#FFFFFF">]</font> <font color="#19CB00">which</font> pip3
/tmp/myVenv/bin/pip3
<font color="#FFFFFF">[</font><font color="#FFFD00">dubrayn</font><font color="#FFFFFF">@</font><font color="#23FD00">dell5290</font><font color="#FFFFFF">(</font><font color="#FD28FF">myVenv</font>):<font color="#14FFFF">/tmp</font><font color="#FFFFFF">]</font> <font color="#19CB00">deactivate</font>
<font color="#FFFFFF">[</font><font color="#FFFD00">dubrayn</font><font color="#FFFFFF">@</font><font color="#23FD00">dell5290</font><font color="#FFFFFF">:</font><font color="#14FFFF">/tmp</font><font color="#FFFFFF">]</font> <font color="#19CB00">which</font> python3
/usr/bin/python3
<font color="#FFFFFF">[</font><font color="#FFFD00">dubrayn</font><font color="#FFFFFF">@</font><font color="#23FD00">dell5290</font><font color="#FFFFFF">:</font><font color="#14FFFF">/tmp</font><font color="#FFFFFF">]</font> <font color="#19CB00">which</font> pip3
/usr/bin/pip3
</code></pre>

---

# Module `venv` - Main commands

## Create the virtual environment

```bash
$ python3 -m venv myVenv
```

:arrow_right: This creates the `myVenv` directory if needed.

## Activate the virtual environment

```bash
$ source myVenv/bin/activate
```

:arrow_right: All "Python" commands will use the `venv` from now.
:bulb: There are other activation scripts for other shells in `myVenv/bin/`.

## De-activate the virtual envronment

```bash
$ deactivate
```

:arrow_right: This command has been defined by the sourced `activate*` script.

---

# Module `venv` - Different Python versions

## Create a virtual environment for different Python versions

<pre><code><font color="#FFFFFF">[</font><font color="#FFFD00">dubrayn</font><font color="#FFFFFF">@</font><font color="#23FD00">dell5290</font><font color="#FFFFFF">:</font><font color="#14FFFF">/tmp</font><font color="#FFFFFF">]</font> <font color="#19CB00"><u style="text-decoration-style:single">sudo</u></font> <font color="#19CB00">apt</font> install python3.11-venv
Reading package lists... Done
Building dependency tree... Done
Reading state information... Done
The following NEW packages will be installed:
  python3.11-venv
0 upgraded, 1 newly installed, 0 to remove and 1 not upgraded.
Need to get 5,730 B of archives.
After this operation, 28.7 kB of additional disk space will be used.
Get:1 http://fr.archive.ubuntu.com/ubuntu jammy-updates/universe amd64 python3.11-venv amd64 3.11.0~rc1-1~22.04 [5,730 B]
Fetched 5,730 B in 0s (43.0 kB/s)<font color="#CECB00">           </font>
Selecting previously unselected package python3.11-venv.
(Reading database ... 528210 files and directories currently installed.)
Preparing to unpack .../python3.11-venv_3.11.0~rc1-1~22.04_amd64.deb ...
Unpacking python3.11-venv (3.11.0~rc1-1~22.04) ...
Setting up python3.11-venv (3.11.0~rc1-1~22.04) ...
<font color="#FFFFFF">[</font><font color="#FFFD00">dubrayn</font><font color="#FFFFFF">@</font><font color="#23FD00">dell5290</font><font color="#FFFFFF">:</font><font color="#14FFFF">/tmp</font><font color="#FFFFFF">]</font> <font color="#19CB00">python3.11</font> -m venv myVenv_cpy311
<font color="#FFFFFF">[</font><font color="#FFFD00">dubrayn</font><font color="#FFFFFF">@</font><font color="#23FD00">dell5290</font><font color="#FFFFFF">:</font><font color="#14FFFF">/tmp</font><font color="#FFFFFF">]</font> <font color="#19CB00">source</font> <u style="text-decoration-style:single">myVenv_cpy311/bin/activate</u>
<font color="#FFFFFF">[</font><font color="#FFFD00">dubrayn</font><font color="#FFFFFF">@</font><font color="#23FD00">dell5290</font><font color="#FFFFFF">(</font><font color="#FD28FF">myVenv_cpy311</font>):<font color="#14FFFF">/tmp</font><font color="#FFFFFF">]</font> <font color="#19CB00">python</font> -V
Python 3.11.0rc1
<font color="#FFFFFF">[</font><font color="#FFFD00">dubrayn</font><font color="#FFFFFF">@</font><font color="#23FD00">dell5290</font><font color="#FFFFFF">(</font><font color="#FD28FF">myVenv_cpy311</font>):<font color="#14FFFF">/tmp</font><font color="#FFFFFF">]</font> <font color="#19CB00">pip</font> -V
pip 22.0.2 from /tmp/myVenv_cpy311/lib/python3.11/site-packages/pip (python 3.11)
</code></pre>

:arrow_right: A `venv` will use the same Python interpreter as the one used to create it (it is a symlink).

---

class: top

# Module `venv` - Package example

.vspace[]

.vspace[]

.vspace[]

## .hcenter[`C++` + `Armadillo` + `swig` + `setuptools` = Python module]

.vspace[]

.vspace[]

.vspace[]

.vspace[]

.vspace[]

.row.w100[
.column.w30[
.tree[
armanpy_python3
* include
    * armanpy
        * armanpy.i
        * armanpy.hpp
        * armanpy_1d.i
        * armanpy_2d.i
        * armanpy_3d.i
        * numpy.i
* **myclass.cpp** :arrow_left:
* myclass.h
* setup.py
* testmod3.i
* test.py
]
]
.column.w70.middle[
## .hcenter[`myclass.cpp`]
```c++
#include "myclass.h"

Myclass::Myclass(arma::mat _mat) : myMat(_mat)
{
}

arma::mat Myclass::testArma(arma::mat A)
{
  return A.t();
}

arma::mat Myclass::getEmptyArma(int n)
{
  return arma::zeros(n, n);
}
```
]
]

---

class: top

# Module `venv` - Package example

.vspace[]

.vspace[]

.vspace[]

## .hcenter[`C++` + `Armadillo` + `swig` + `setuptools` = Python module]

.vspace[]

.vspace[]

.vspace[]

.vspace[]

.vspace[]

.row.w100[
.column.w30[
.tree[
armanpy_python3
* include
    * armanpy
        * armanpy.i
        * armanpy.hpp
        * armanpy_1d.i
        * armanpy_2d.i
        * armanpy_3d.i
        * numpy.i
* myclass.cpp
* **myclass.h** :arrow_left:
* setup.py
* testmod3.i
* test.py
]
]
.column.w70.middle[
## .hcenter[`myclass.h`]
```c++
#ifndef MYCLASS_H
#define MYCLASS_H

#include <armadillo>

class Myclass
{
  public:
  Myclass(arma::mat _mat = arma::mat());
  arma::mat testArma(arma::mat);
  arma::mat getEmptyArma(int n);
  arma::mat myMat;
};

#endif
```
]
]

---

class: top

# Module `venv` - Package example

.vspace[]

.vspace[]

.vspace[]

## .hcenter[`C++` + `Armadillo` + `swig` + `setuptools` = Python module]

.vspace[]

.vspace[]

.vspace[]

.vspace[]

.vspace[]

.row.w100[
.column.w30[
.tree[
armanpy_python3
* include
    * armanpy
        * armanpy.i
        * armanpy.hpp
        * armanpy_1d.i
        * armanpy_2d.i
        * armanpy_3d.i
        * numpy.i
* myclass.cpp
* myclass.h
* **setup.py** :arrow_left:
* testmod3.i
* test.py
]
]
.column.w70.middle[
## .hcenter[`setup.py`]
```python
from setuptools import setup, Extension

module1 = Extension('_testmod3',
                    include_dirs = ['./include/armanpy/'],
                    libraries = ['m', 'z', 'armadillo'],
                    sources = ['testmod3.i', 'myclass.cpp'],
                    swig_opts = ["-c++", "-Wall", "-I.", "-I./include/armanpy/"])

setup (name = 'package_test',
       py_modules = ['testmod3'],
       version = '1.0',
       description = 'This is a test package',
       ext_modules = [module1])
```
]
]

---

class: top

# Module `venv` - Package example

.vspace[]

.vspace[]

.vspace[]

## .hcenter[`C++` + `Armadillo` + `swig` + `setuptools` = Python module]

.vspace[]

.vspace[]

.vspace[]

.vspace[]

.vspace[]

.row.w100[
.column.w30[
.tree[
armanpy_python3
* include
    * armanpy
        * armanpy.i
        * armanpy.hpp
        * armanpy_1d.i
        * armanpy_2d.i
        * armanpy_3d.i
        * numpy.i
* myclass.cpp
* myclass.h
* setup.py
* **testmod3.i** :arrow_left:
* test.py
]
]
.column.w70.middle[
## .hcenter[`testmod3.i`]
```swig
%module testmod3
%include "stl.i"
%include "std_map.i"
%include "std_string.i"
%include "std_vector.i"
%include "std_vectora.i"
%include "exception.i"

namespace std
{
  %template(map_string_int) map<string, int>;
  %template(map_string_double) map<string, double>;
  %template(map_string_string) map<string, string>;
}

%exception
{
[...]
}

%{
#define SWIG_FILE_WITH_INIT
#include "myclass.h"
%}

%include "armanpy.i"

%include "myclass.h"
```
]
]

---

class: top

# Module `venv` - Package example

.vspace[]

.vspace[]

.vspace[]

## .hcenter[`C++` + `Armadillo` + `swig` + `setuptools` = Python module]

.vspace[]

.vspace[]

.vspace[]

.vspace[]

.vspace[]

.row.w100[
.column.w30[
.tree[
armanpy_python3
* include
    * armanpy
        * armanpy.i
        * armanpy.hpp
        * armanpy_1d.i
        * armanpy_2d.i
        * armanpy_3d.i
        * numpy.i
* myclass.cpp
* myclass.h
* setup.py
* testmod3.i
* **test.py** :arrow_left:
]
]
.column.w70.middle[
## .hcenter[`test.py`]
```python
#!/usr/bin/env python3

import testmod3
import numpy as np

numpyArray = np.array([[0.1, 0.2], [0.3, 0.4]], dtype = np.float64, order = 'F')
print("Initial object:")
print(numpyArray)

mc = testmod3.Myclass(numpyArray)
print("Object in the C++ class (constructor with argument):")
print(mc.myMat)

mc = testmod3.Myclass()
print("Object in the C++ class (empty constructor):")
print(mc.myMat)


a = mc.getEmptyArma(3)
a[0,1] = 1.0
print("Object returned by the C++ method getEmptyArma() and modified:")
print(a)

print("Object returned by the C++ method testArma() (transposition):")
print(mc.testArma(a))
```
]
]

---

# Module `venv` - Package example

## .hcenter[Build and install the package in a `venv` with `setuptools`]

.hcenter[
<asciinema-player src="scripts/setuptools.cast"></asciinema-player>
]

:arrow_right: Installed packages are stored inside the `venv` directory.
:warning: This direct invocation of `setup.py` is **deprecated**. One must use **`pip`** instead.

---

# Module `venv` - Package example

## .hcenter[Build and install the package in a `venv` with `pip`]

.hcenter[
<asciinema-player src="scripts/pip_module.cast"></asciinema-player>
]

:arrow_right: "`pip` is the **prefered** installer program."
:arrow_right: `pip` should be installed by default on a standard Python installation.

---

# Module `pip` - ???

.hcenter.shadow.w70[![](images/fry.jpg)]

## .hcenter[What was this "`pip install`" thing ?]


---

# Module `pip` - Install packages

.hcenter[:arrow_right: `pip` is a package management system, dedicated to Python packages.]

## :arrow_right: `pip` can build and install **local packages**

<pre><code><font color="#FFFFFF">[</font><font color="#FFFD00">dubrayn</font><font color="#FFFFFF">@</font><font color="#23FD00">dell5290</font><font color="#FFFFFF">(</font><font color="#FD28FF">myVenv</font>):<font color="#14FFFF">armanpy_python3</font><font color="#FFFFFF">]</font> <font color="#19CB00">pip</font> install <u style="text-decoration-style:single">.</u>
Processing /tmp/armanpy_python3
  Preparing metadata (setup.py) ... done
Using legacy 'setup.py install' for package-test, since package 'wheel' is not installed.
Installing collected packages: package-test
  Running setup.py install for package-test ... done
Successfully installed package-test-1.0</code></pre>


## :arrow_right: `pip` can fetch, [build] and install **remote packages**

<pre><code> <font color="#FFFFFF">[</font><font color="#FFFD00">dubrayn</font><font color="#FFFFFF">@</font><font color="#23FD00">dell5290</font><font color="#FFFFFF">(</font><font color="#FD28FF">myVenv</font>):<font color="#14FFFF">armanpy_python3</font><font color="#FFFFFF">]</font> <font color="#19CB00">pip</font> install numpy
Collecting numpy
  Using cached numpy-1.24.3-cp310-cp310-manylinux_2_17_x86_64.manylinux2014_x86_64.whl (17.3 MB)
Installing collected packages: numpy
Successfully installed numpy-1.24.3
<font color="#FFFFFF">[</font><font color="#FFFD00">dubrayn</font><font color="#FFFFFF">@</font><font color="#23FD00">dell5290</font><font color="#FFFFFF">(</font><font color="#FD28FF">myVenv</font>):<font color="#14FFFF">armanpy_python3</font><font color="#FFFFFF">]</font> <font color="#19CB00">pip</font> install xkcd==2.4.0
Collecting xkcd==2.4.0
  Downloading xkcd-2.4.0.zip (14 kB)
  Preparing metadata (setup.py) ... done
Using legacy 'setup.py install' for xkcd, since package 'wheel' is not installed.
Installing collected packages: xkcd
  Running setup.py install for xkcd ... done
Successfully installed xkcd-2.4.0</code></pre>

:arrow_right: Use "`pip install package==x.y.z`" to install a **specific version** of a package.
:arrow_right: You can use "`python3 -m pip command`" instead of "`pip command`".

---

# Module `pip` - Manage packages

## :arrow_right: `pip` can **list** installed packages in the current `venv`

<pre><code><font color="#FFFFFF">[</font><font color="#FFFD00">dubrayn</font><font color="#FFFFFF">@</font><font color="#23FD00">dell5290</font><font color="#FFFFFF">(</font><font color="#FD28FF">myVenv</font>):<font color="#14FFFF">armanpy_python3</font><font color="#FFFFFF">]</font> <font color="#19CB00">pip</font> list
Package      Version
------------ -------
numpy        1.24.3
package-test 1.0
pip          22.0.2
setuptools   59.6.0
xkcd         2.4.0</code></pre>

## :arrow_right: `pip` can **uninstall** packages in the current `venv`

<pre><code><font color="#FFFFFF">[</font><font color="#FFFD00">dubrayn</font><font color="#FFFFFF">@</font><font color="#23FD00">dell5290</font><font color="#FFFFFF">(</font><font color="#FD28FF">myVenv</font>):<font color="#14FFFF">armanpy_python3</font><font color="#FFFFFF">]</font> <font color="#19CB00">pip</font> uninstall package-test
Found existing installation: package-test 1.0
Uninstalling package-test-1.0:
  Would remove:
    /tmp/armanpy_python3/myVenv/lib/python3.10/site-packages/_testmod3.cpython-310-x86_64-linux-gnu.so
    /tmp/armanpy_python3/myVenv/lib/python3.10/site-packages/package_test-1.0.egg-info
    /tmp/armanpy_python3/myVenv/lib/python3.10/site-packages/testmod3.py
Proceed (Y/n)?
  Successfully uninstalled package-test-1.0
<font color="#FFFFFF">[</font><font color="#FFFD00">dubrayn</font><font color="#FFFFFF">@</font><font color="#23FD00">dell5290</font><font color="#FFFFFF">(</font><font color="#FD28FF">myVenv</font>):<font color="#14FFFF">armanpy_python3</font><font color="#FFFFFF">]</font> <font color="#19CB00">pip</font> list
Package    Version
---------- -------
numpy      1.24.3
pip        22.0.2
setuptools 59.6.0
xkcd       2.4.0</code></pre>

---

# Module `pip` - Manage packages

## :arrow_right: `pip` can **update** installed packages in the current `venv`

<pre><code><font color="#FFFFFF">[</font><font color="#FFFD00">dubrayn</font><font color="#FFFFFF">@</font><font color="#23FD00">dell5290</font><font color="#FFFFFF">(</font><font color="#FD28FF">myVenv</font>):<font color="#14FFFF">armanpy_python3</font><font color="#FFFFFF">]</font> <font color="#19CB00">pip</font> install xkcd -U
Requirement already satisfied: xkcd in ./myVenv/lib/python3.10/site-packages (2.4.0)
Collecting xkcd
  Using cached xkcd-2.4.2-py3-none-any.whl
Installing collected packages: xkcd
  Attempting uninstall: xkcd
    Found existing installation: xkcd 2.4.0
    Uninstalling xkcd-2.4.0:
      Successfully uninstalled xkcd-2.4.0
      Successfully installed xkcd-2.4.2</code></pre>


## :arrow_right: `pip` can **list versions** of a given package

<pre><code><font color="#FFFFFF">[</font><font color="#FFFD00">dubrayn</font><font color="#FFFFFF">@</font><font color="#23FD00">dell5290</font><font color="#FFFFFF">(</font><font color="#FD28FF">myVenv</font>):<font color="#14FFFF">armanpy_python3</font><font color="#FFFFFF">]</font> <font color="#19CB00">pip</font> install xkcd==
<font color="#CC0403">ERROR: Could not find a version that satisfies the requirement xkcd== (from versions: 2.0, 2.1, 2.2, 2.3, 2.3.1, 2.3.2, 2.3.3, 2.4.0, 2.4.1, 2.4.2)</font>
<font color="#CC0403">ERROR: No matching distribution found for xkcd==</font>
</code></pre>

## :arrow_right: `pip` cannot **search** for available packages anymore :cry:

<pre><code><font color="#FFFFFF">[</font><font color="#FFFD00">dubrayn</font><font color="#FFFFFF">@</font><font color="#23FD00">dell5290</font><font color="#FFFFFF">(</font><font color="#FD28FF">myVenv</font>):<font color="#14FFFF">armanpy_python3</font><font color="#FFFFFF">]</font> <font color="#19CB00">pip</font> search xkcd
<font color="#CC0403">ERROR: XMLRPC request failed [code: -32500]</font>
<font color="#CC0403">RuntimeError: PyPI no longer supports 'pip search' (or XML-RPC search). Please use https://pypi.org/search (via a browser) instead. See https://warehouse.pypa.io/api-reference/xml-rpc.html#deprecated-methods for more information.</font>
</code></pre>

:arrow_right: As stated, go to `https://pypi.org/search` to search for packages.

---

# Module `pip` - "remote packages" ?

.hcenter.shadow.w70[![](images/fry.jpg)]

## .hcenter[Where do the remote packages come from ?]

---

# `PyPi` - The Python Package Index

.hcenter.w40[![](images/logo-pypi.svg)]

:arrow_right: "PyPi helps you find and install software **developed and shared** by the Python community."
:arrow_right: `https://pypi.org`

---

# `PyPi` - "by the Python community" ?

.hcenter.w70[![](images/fry_happy.png)]

## .hcenter[So I can share my Python packages ?]

---

class: top

# `PyPi` - Creating a compliant package

.vspace[]

.vspace[]

.vspace[]

## .hcenter[Pure Python module]

.vspace[]

.vspace[]

.vspace[]

.vspace[]

.vspace[]

.row.w100[
.column.w30.middle[
.tree[
pyexample
* LICENSE
* pyexample
    * `__`init`__`.py
    * module_test_0.py
    * module_test_1.py
    * module_test_2.py
* README.rst
* **setup.py** :arrow_left:
]
]
.column.w70.middle[
## .hcenter[`setup.py`]
```python
from setuptools import setup

setup(
    name='pyexample',
    version='0.1.0',
    description='A example Python package',
    url='https://github.com/shuds13/pyexample',
    author='Stephen Hudson',
    author_email='shudson@anl.gov',
    license='BSD 2-clause',
    packages=['pyexample'],
    install_requires=['mpi4py>=2.0',
                      'numpy',
                      ],

    classifiers=[
        'Development Status :: 1 - Planning',
        'Intended Audience :: Science/Research',
        'License :: OSI Approved :: BSD License',
        'Operating System :: POSIX :: Linux',
        'Programming Language :: Python :: 2',
        'Programming Language :: Python :: 2.7',
        'Programming Language :: Python :: 3',
        'Programming Language :: Python :: 3.4',
        'Programming Language :: Python :: 3.5',
    ],
)
```
]
]

:arrow_right: Example inspired from [https://github.com/shuds13/pyexample](https://github.com/shuds13/pyexample)


---

class: top

# `PyPi` - Creating a compliant package

.vspace[]

.vspace[]

.vspace[]

## .hcenter[Pure Python module]

.vspace[]

.vspace[]

.vspace[]

.vspace[]

.vspace[]

.row.w100[
.column.w30.middle[
.tree[
pyexample
* LICENSE
* pyexample
    * **`__`init`__`.py** :arrow_left:
    * module_test_0.py
    * module_test_1.py
    * module_test_2.py
* README.rst
* setup.py
]
]
.column.w70.middle[
## .hcenter[`pyexample/__init__.py`]
```python
"""
pyexample.

An example python library.
"""

__version__ = "0.1.0"
__author__ = 'Stephen Hudson'
__credits__ = 'Argonne National Laboratory'

```
]
]

.hcenter[:warning: Two version numbers...]

## Create a source distribution

```bash
$ python setup.py sdist
```

:arrow_right: This creates a `pyexample-0.1.0.tar.gz` file that can be distributed.
:arrow_right: To customize the content of the archive, you can use a `MANIFEST.in` file (cf. next slides).
:arrow_right: To send the file to `PyPi`, use the `twine` module (cf. next slides).


---

# `PyPi` - Create a compliant package

.hcenter.shadow.w70[![](images/fry.jpg)]

## .hcenter[I want to use `C++`, `Armadillo` and `swig` in my Python module !]

---

# `PyPi` - Create a compliant binary package

## Binary packages

* They are called **`wheels`** (the `egg` format is obsolete now).
* They (obviously) depend on the architecture and the environment.
* They speed up the distribution process by avoiding any recompilation.

:arrow_right: Let's build and distribute a `wheel` file then ?

:warning: `PyPi` forbids the upload of generic linux binary wheels.

:arrow_right: Only a "standard" `wheel` binary format is accepted by `PyPi`: **`manylinux`**

## The `manylinux` project

* [https://github.com/pypa/manylinux](https://github.com/pypa/manylinux)
* Goal: "to provide a convenient way to distribute binary Python extensions as wheels on Linux".
* They provide a small set of **platform tags**. Among them, PEP 600 is supposed to be **future-proof**.
* PEP 600: a wheel tagged `manylinux_x_y` shall work on any distro based on `glibc==x.y`.
* Such `manylinux_x_y` tagged wheels should work with `pip>=20.3` and `CPython>=3.8.10`, `CPython>=3.9.5` and `CPython>=3.10.0`.

:arrow_right: To generate `manylinux_x_y` compatible wheels, **Docker images** are available with different toolchains and architectures.


---

# `manylinux` - Build and upload to `PyPi`

## .hcenter[`C++` + `Armadillo` + `swig` + `setuptools` = Python module]

.vspace[]

.vspace[]

.vspace[]

:arrow_right: The files are in **`examples/armanpy_pip`**.
:arrow_right: We are using the `AlmaLinux 8` based Docker image `quay.io/pypa/manylinux_2_28_x86_64`.
:arrow_right: For testing, the package is uploaded to `test.pypi.org` instead of `pypi.org`.
:arrow_right: Create an account on [https://test.pypi.org/account/register](https://test.pypi.org/account/register) to upload.

## Generating and uploading the package

```bash
$ docker run -it --volume $(pwd):/root/ quay.io/pypa/manylinux_2_28_x86_64
[docker] cd root/
[docker] yum -y install epel-release
[docker] yum -y update
[docker] yum -y install swig armadillo-devel boost-devel
[docker] /opt/python/cp310-cp310/bin/pip3.10 install wheel setuptools numpy twine
[docker] /opt/python/cp310-cp310/bin/pip3.10 wheel . --no-deps -w output
[docker] auditwheel repair output/armanpypsa-*-linux_x86_64.whl -w output
[docker] twine upload output/armanpypsa-*-manylinux_2_28_x86_64.whl -r testpypi
```

## Installing the package from `test.pypi.org`

```bash
$ python3 -m venv venv
$ source venv/bin/activate
$ pip3 install --index-url https://test.pypi.org/simple/ --extra-index-url https://pypi.org/simple/ armanpypsa
$ test_package/test.py
```

:arrow_right: The dependencies (`numpy`) are installed from `pypi.org`.

---

class: top

# `manylinux` - Some explanations

.vspace[]

.vspace[]

.vspace[]

.row.w100[
.column.w30[
.tree[
armanpy_pip/
* armanpy/
    * [...]
* armanpypsa.i
* go.sh
* LICENSE
* MANIFEST.in
* **pyproject.toml** :arrow_left:
* README.md
* setup.py
* src/
    * myclass.cpp
    * myclass.h
* test_package/
    * test.py
]
]
.column.w70.middle[
## .hcenter[`pyproject.toml`]
```toml
[build-system]
requires = ["setuptools>=59.6.0", "wheel", "numpy"]
build-backend = "setuptools.build_meta"

[project]
name = "armanpypsa"
version = "0.0.11"
authors = [
  { name="Dubray N.", email="noel.dubray@gmail.com" },
]
description = "Test package for teaching purposes"
readme = "README.md"
requires-python = ">=3.7"
classifiers = [
    "Programming Language :: Python :: 3",
    "License :: OSI Approved :: MIT License",
    "Operating System :: OS Independent",
]
dependencies = ["numpy"]

[project.urls]
"Homepage" = "https://github.com/dubrayn/dubrayn.github.io"
"Bug Tracker" = "https://github.com/dubrayn/dubrayn.github.io/issues"
```

:arrow_right: Notice the different dependencies:
* `build-system/requires` (build)
* `project/dependencies` (runtime)

:warning: `project/version` must not exist in the remote package index.
]
]

---

class: top

# `manylinux` - Some explanations

.vspace[]

.vspace[]

.vspace[]

.row.w100[
.column.w30[
.tree[
armanpy_pip/
* armanpy/
    * [...]
* armanpypsa.i
* go.sh
* LICENSE
* **MANIFEST.in** :arrow_left:
* pyproject.toml
* README.md
* setup.py
* src/
    * myclass.cpp
    * myclass.h
* test_package/
    * test.py
]
]
.column.w70.middle[
## .hcenter[`MANIFEST.in`]
```manifest
include LICENSE
include README.md
recursive-include src *.cpp
recursive-include src *.h
recursive-include armanpy *.hpp
recursive-include armanpy *.i
```
:arrow_right: List the files to be included in the `venv` for the build process.
:arrow_right: Wildcards are accepted.
]
]

---

class: top

# `manylinux` - Some explanations

.vspace[]

.vspace[]

.vspace[]

.row.w100[
.column.w30[
.tree[
armanpy_pip/
* armanpy/
    * [...]
* armanpypsa.i
* go.sh
* LICENSE
* MANIFEST.in
* pyproject.toml
* README.md
* requirements.txt
* **setup.py** :arrow_left:
* src/
    * myclass.cpp
    * myclass.h
* test_package/
    * test.py
]
]
.column.w70.middle[
## .hcenter[`setup.py`]
```python
from setuptools import setup, Extension

# fix an annoying bug with setuptools
# https://stackoverflow.com/questions/29477298/setup-py-run-build-ext-before-anything-else/48942866#48942866

from setuptools.command.build_py import build_py as _build_py

class build_py(_build_py):
    def run(self):
        self.run_command("build_ext")
        return super().run()

module1 = Extension('_armanpypsa',
                    include_dirs = ['./armanpy/', 'src/', '/opt/python/cp310-cp310/lib/python3.10/site-packages/numpy/core/include/'],
                    libraries = ['m', 'z', 'armadillo'],
                    sources = ['armanpypsa.i', 'src/myclass.cpp'],
                    swig_opts = ["-c++", "-Wall", "-I.", "-I./armanpy/", "-Isrc/"])

setup (name = 'armanpypsa',
       py_modules = ['armanpypsa'],
       version = '1.0',
       description = 'This is a test package',
       options = {"build_ext": {"inplace": False}},
       cmdclass = {'build_py' : build_py}, # fix for the bug
       ext_modules = [module1])
```
]
]

:arrow_right: Some tweaks to get it to work:
* workaround for a bug in `setuptools` (order of `build` and `build_ext`),
* hardcoded include path for `numpy` (not sure how to do it better, feel free to PR).

---

class: top

# `manylinux` - Some explanations

.vspace[]

.vspace[]

.vspace[]

.row.w100[
.column.w30[
.tree[
armanpy_pip/
* armanpy/
    * [...]
* armanpypsa.i
* **go.sh** :arrow_left:
* LICENSE
* MANIFEST.in
* pyproject.toml
* README.md
* requirements.txt
* setup.py
* src/
    * myclass.cpp
    * myclass.h
* test_package/
    * test.py
]
]
.column.w70.middle[
## .hcenter[`go.sh` (launched in the container)]
```bash
#!/bin/bash

yum -y install epel-release
yum -y update
yum -y install swig armadillo-devel boost-devel
/opt/python/cp310-cp310/bin/pip3.10 install wheel setuptools numpy twine
/opt/python/cp310-cp310/bin/pip3.10 wheel . --no-deps -w output
auditwheel repair output/armanpypsa-*-linux_x86_64.whl -w output
/opt/python/cp310-cp310/bin/twine upload output/armanpypsa-*-manylinux_2_28_x86_64.whl -r testpypi
```
:arrow_right: `armadillo-devel` and its deps. are installed from the `epel` repo,
:arrow_right: The chosen Python version is `3.10`.
:arrow_right: The build dependencies are manually installed.
:arrow_right: `auditwheel` creates the final `manylinux_x_y` wheel.
:arrow_right: `twine` is used to upload the wheel directly from the container.
]
]

---

# `manylinux` - Screencast

.hcenter[
<asciinema-player src="scripts/manylinux.cast"></asciinema-player>
]

.hcenter[
:warning: This is a **long** screencast (>7 min), even if the Docker image was already present.
]

---

# Conclusions

## Virtual environments are powerful

:arrow_right: They allow to develop different Python projects on the same computer.
:arrow_right: They allow to decouple and isolate the different Python installs and their associated packages.

## Virtual environments are easy to use and to manage

:arrow_right: Two standard modules to remember: `venv` and `pip`
:arrow_right: Several intuitive commands to remember
:arrow_right: `python -m venv --help`
:arrow_right: `python -m pip --help`

## Virtual environments are used by other tools

:arrow_right: deployment testing with tox ([https://tox.wiki](https://tox.wiki))
:arrow_right: build process (`build`, `pip`...)
:arrow_right: CI / CD

## `PyPi` is a blessing

:arrow_right: Every Python package is one `pip` command away ! With its dependencies !
:arrow_right: Deploy almost everything almost everywhere (whatever your distro, environment, architecture...) !
:arrow_right: It is **relatively easy** to publish your packages, even complex ones.

.vspace[]

## .hcenter[:arrow_right: One Python project ? One virtual environment for its dependencies.]
